OS Test 5V Automatic Wiring Assembly Tester for Diode/Zener Diode with 0-10V/0.1mA/1mA
OS Test 5V Automatic Wiring Assembly Tester
Product Description:
The low-voltage wiring harness tester is an instrument used to test and verify the connectivity performance of low-voltage wiring harnesses. It is mainly used in the fields of automobiles, aerospace, electronics, and more, to detect parameters such as the connectivity, short circuit, open circuit, resistance, and insulation resistance of the wiring harness. In the automotive industry, the low-voltage wiring harness tester can be used in the R&D, production, and maintenance processes of the wiring harness to ensure the quality and reliability of the wiring harness. In the aerospace and electronics industries, it can be used to test the stability and reliability of the wiring harness in harsh environments. The application scenarios of the low-voltage wiring harness tester are very extensive, and it can help improve the quality and reliability of the wiring harness, reduce the risk of faults, and ensure the normal operation of the equipment.
Features:
- Product Name: Automatic Cable Harness Tester
- AC Withstand Voltage Test: 30-1000V
- Four-wire DC Resistance Test: 10μΩ-100Ω
- Display: PC
- Diode/Zener Diode: 0-10V/0.1mA/1mA
- Operating Temperature: 0-40°C
- Smart Wiring Harness Testing Machine
- Robotic Wire Harness Verification Equipment
Technical Parameters:
| Product Name |
Automatic Cable Harness Tester |
| Display |
PC |
| Four-wire DC Resistance Test |
10μΩ-100Ω |
| Test Mode |
4-Wire Or 2-wire (mixed Test) |
| Points |
128/256/512/1024/...20480 |
| DC Leakage Test |
0.1μA-5mA |
| AC Leakage Test |
1μA-10mA |
| DC Resistance Test |
0.1Ω-1MΩ |
| Power Supply |
220V AC |
| Weight |
25/17kg |
| Operating Temperature |
0-40°C |
| Key Features |
Robotic Wire Harness Verification Equipment, Remote-Controlled Cable Harness Tester, Automatic Wiring Assembly Tester |
Applications:
Automatic Cable Harness Tester - SAIMR5000
Brand Name: SAIMR
Model Number: SAIMR5000
Place of Origin: CHINA
Certification: CE,ISO9001
Minimum Order Quantity: 1 SET
Price: To be negotiated
Packaging Details: Packing in wooden crates
Delivery Time: To be negotiated
Payment Terms: To be negotiated
Supply Ability: To be negotiated
Product Name: SAIMR5000
Dimensions: 483*265*510/483*183*510
Diode/Zener Diode: 0-10V/0.1mA/1mA
DC Resistance Test: 0.1Ω-1MΩ
Points: 128/256/512/1024/...20480
Introducing the SAIMR5000 - an innovative and efficient Automated Wire Harness Tester designed to increase productivity and accuracy in cable harness testing. Engineered and manufactured in China, this tester is certified with CE and ISO9001, ensuring its high quality and reliability. The minimum order quantity is only 1 set, making it accessible for small businesses and large corporations alike.
With its compact dimensions of 483*265*510/483*183*510, the SAIMR5000 is a space-saving solution for cable harness testing. It is equipped with advanced technology that allows for precise testing of diodes and zener diodes with a range of 0-10V/0.1mA/1mA. The DC Resistance Test function can handle a wide range of resistances from 0.1Ω to 1MΩ, ensuring accurate and efficient testing of cable harnesses.
The SAIMR5000 also offers a variety of testing points, including 128/256/512/1024/...20480, to cater to different testing needs and requirements. Its automated process eliminates human error and reduces testing time, making it an essential tool for cable harness manufacturers and suppliers.
This state-of-the-art tester is proudly branded as SAIMR, a trusted name in the industry known for its top-quality products. With its sturdy construction and reliable performance, the SAIMR5000 is built to withstand heavy usage and provide consistent results. It comes with packaging in wooden crates for secure transportation and can be delivered in a timely manner as per the customer's negotiation.
Experience the convenience and efficiency of automated cable harness testing with the SAIMR5000. Contact us now to negotiate the price and supply for this game-changing product.
FAQ:
- Q: What is the brand of this product?
- A: The brand of this product is SAIMR.
- Q: What is the model number of this product?
- A: The model number of this product is SAIMR5000.
- Q: Where is this product manufactured?
- A: This product is manufactured in China.
- Q: Does this product have any certifications?
- A: Yes, this product is certified by CE and ISO9001.
- Q: What is the minimum order quantity for this product?
- A: The minimum order quantity for this product is 1 set.
