4 Wire Or 2 Wire Automated Wire Harness Tester For Diode / Zener Diode Testing

4 Wire Or 2 Wire Automated Wire Harness Tester For Diode / Zener Diode Testing

Zener Diode Testing Wire Harness Tester

2 Wire Automated Wire Harness Tester

4 Wire Automated Wire Harness Tester

Place of Origin:

CHINA

Brand Name:

SAIMR

Certification:

CE,ISO9001

Model Number:

SAIMR5000

Contact Us

Request A Quote
Product Details
DC Leakage Test:
0.1μA-5mA
AC Withstand Voltage Test:
30-1000V
Dimensions:
483*265*510/483*183*510
Operating Temperature:
0-40°C
AC Leakage Test:
1μA-10mA
Product Name:
SAIMR5000
Power Supply:
220V AC
DC Withstand Voltage Test:
30-1500V
Payment & Shipping Terms
Minimum Order Quantity
1 SET
Price
To be negotiated
Packaging Details
Packing in wooden crates
Delivery Time
To be negotiated
Payment Terms
To be negotiated
Supply Ability
To be negotiated
Product Description

4-Wire or 2-Wire Automated Wire Harness Tester Perfect for Diode/Zener Diode Testing



Cable Harness Tester

Product Description:

The Automatic Cable Harness Tester is a high-performance and efficient robotic wire harness verification equipment designed to automate the testing process of cable harnesses. It is an essential tool for manufacturers and engineers to ensure the accuracy and functionality of their wiring assemblies.

Key Features
  • Points: With a range of 128 to 20480 points, the Automatic Cable Harness Tester is capable of testing wire harnesses of various sizes and complexities.
  • AC Leakage Test: The tester can detect leakage currents ranging from 1μA to 10mA, ensuring the safety and reliability of the tested cable harness.
  • Standard Configuration: The package comes with a USB drive, power cord, network cable, and a pointing pen, providing users with all the necessary tools for testing.
  • DC Withstand Voltage Test: The tester can withstand voltage ranging from 30 to 1500V, ensuring the quality and durability of the tested cable harness.
  • Diode/Zener Diode: With a testing range of 0-10V/0.1mA/1mA, the tester can accurately detect diodes and zener diodes in the cable harness.
Benefits

The Automatic Cable Harness Tester offers a wide range of benefits to its users, including:

  • User-friendly: The tester is designed with a simple and intuitive interface, making it easy for users to operate and understand.
  • Versatility: With a wide range of testing capabilities, the tester can be used for various types of cable harnesses, saving time and costs for manufacturers.
  • Safety: The tester is equipped with multiple safety features, ensuring the safety of the user and the tested cable harness.
  • Reliability: The tester is built with high-quality materials and advanced technology, providing accurate and reliable testing results.

Overall, the Automatic Cable Harness Tester is an essential tool for any manufacturer or engineer looking to streamline their testing process, improve efficiency, and ensure the quality and functionality of their cable harnesses.



Features:

  • Product Name: Automatic Cable Harness Tester
  • Display: PC
  • DC Withstand Voltage Test: 30-1500V
  • Diode/Zener Diode: 0-10V/0.1mA/1mA
  • Test Mode: 4-Wire or 2-Wire (Mixed Test)
  • Standard Configuration: USB Drive, Power Cord, Network Cable, Pointing Pen
  • Smart Wiring Harness Testing Machine
  • Automatic Wiring Assembly Tester


Technical Parameters:

Product Name SAIMR5000
Power Source Electric
Points 128/256/512/1024/...20480
IR Test 1MΩ-10GΩ (30V-1500V)
DC Leakage Test 0.1μA-5mA
Standard Configuration USB Drive, Power Cord, Network Cable, Pointing Pen
AC Withstand Voltage Test 30-1000V
DC Withstand Voltage Test 30-1500V
OS Test (5V) 2kΩ-200kΩ (optional 20kΩ-1000kΩ) / ±5%
Diode/Zener Diode 0-10V / 0.1mA / 1mA


Applications:

SAIMR5000 Automatic Cable Harness Tester

The SAIMR5000 is a state-of-the-art automated wire harness tester designed and manufactured by SAIMR in China. It is a smart wiring harness testing machine that is specifically designed for testing cable assemblies. The SAIMR5000 is widely used in various industries such as automotive, aerospace, electronics, and telecommunications for its reliable and accurate testing capabilities.

Application

The SAIMR5000 is perfect for testing cable assemblies of different types and sizes, making it suitable for a wide range of applications. It is commonly used in the production and quality control process of cable manufacturers to ensure that their products meet the required standards. The SAIMR5000 is also used in the assembly line of various industries to ensure that the cable harnesses are properly connected and functioning before installation.

Scene

Imagine a large automotive factory where hundreds of cars are produced every day. Each car has thousands of electrical components that need to be connected through cable harnesses. The SAIMR5000 is used in the production line to test the cable harnesses of each car, ensuring that they are properly connected and functioning. This not only ensures the safety and reliability of the car but also saves time and cost for the manufacturer.

Product Attributes
  • Brand Name: SAIMR
  • Model Number: SAIMR5000
  • Place of Origin: China
  • Certification: CE, ISO9001
  • Minimum Order Quantity: 1 set
  • Price: To be negotiated
  • Packaging Details: Packing in wooden crates
  • Delivery Time: To be negotiated
  • Payment Terms: To be negotiated
  • Supply Ability: To be negotiated
  • DC Leakage Test: 0.1μA-5mA
  • AC Leakage Test: 1μA-10mA
  • OS test(5V): 2kΩ-200kΩ (optional 20kΩ-1000kΩ) / ±5%
  • Points: 128/256/512/1024/...20480

The SAIMR5000 is equipped with advanced features such as DC and AC leakage testing, as well as OS testing with a range of 2kΩ-200kΩ (optional 20kΩ-1000kΩ) and an accuracy of ±5%. It also has the capability to test up to 20480 points, providing a comprehensive and detailed analysis of the cable harnesses.

With its high precision and efficiency, the SAIMR5000 is a reliable and cost-effective solution for cable harness testing. Its user-friendly interface and customizable testing options make it a versatile tool for various industries. Trust SAIMR for all your cable assembly testing needs with our SAIMR5000 Automatic Cable Harness Tester.



FAQ:

Frequently Asked Questions

 Q: Why is the SAIMR5000 low-voltage wire harness comprehensive test system needed in the military industry?



A: The military industry has extremely high requirements for product reliability and safety. The low-voltage wire harness comprehensive test system can ensure the connection quality and stability of the wire harness, thereby reducing the risk of failures and improving product reliability and safety.



Q: What role can the low-voltage wire harness comprehensive test system play in the military industry?



A: The low-voltage wire harness comprehensive test system can perform comprehensive tests on the wire harness in military products, including conductivity, insulation, resistance, and voltage withstand, to ensure the quality and reliability of the wire harness.



Q: What are the special requirements for the low-voltage wire harness comprehensive test system in the military industry due to the harsh environment of the military industry?



A: Products in the military industry usually operate in harsh environments such as high and low temperatures, humidity, vibration, etc. Therefore, the low-voltage wire harness comprehensive test system needs to have strong anti-interference ability, good stability, and high accuracy to meet the special needs of the military industry.



Q: How does the low-voltage wire harness comprehensive test system improve the production efficiency of military products?



A: The low-voltage wire harness comprehensive test system can realize automated testing, which greatly shortens the test time and improves production efficiency. At the same time, the system can quickly detect faults in the wire harness, reducing repair time and cost.



Q: What help does the low-voltage wire harness comprehensive test system provide for quality control of military products?



A: Through comprehensive testing of low-voltage wire harnesses, potential quality problems can be detected and eliminated in a timely manner, ensuring that the quality of military products meets strict standards and requirements.

4 Wire Or 2 Wire Automated Wire Harness Tester For Diode / Zener Diode Testing 04 Wire Or 2 Wire Automated Wire Harness Tester For Diode / Zener Diode Testing 1
