Low Voltage Wire Tester
The Low Voltage Wire Tester is a highly versatile and efficient electrical testing instrument designed for low voltage applications. It is an essential tool for electricians, technicians, and engineers working with low voltage wires in various industries such as telecommunications, electronics, and electrical power distribution.
Optional Configurations
This product comes with optional configurations to suit different testing needs:
- Port Adapter Board - allows for easy connection to different types of low voltage wires and terminals.
- Test Cable - provides a secure and stable connection for accurate testing results.
- Computer - enables data logging and analysis for more comprehensive testing.
- Temperature Probe - measures temperature changes during testing for more precise results.
- Multi-channel Temperature Module - allows for simultaneous testing of multiple wires and terminals.
Diode/Zener Diode Testing
The Low Voltage Wire Tester is equipped with advanced diode and zener diode testing capabilities, making it an ideal tool for testing and troubleshooting low voltage circuits. It can accurately measure the voltage and current of diodes within the range of 0-10V and 0.1mA/1mA respectively.
AC Withstand Voltage Test
With a range of 30V-1000V and an accuracy of ±3%, this tester is capable of conducting AC withstand voltage tests on low voltage wires and terminals. This feature ensures the safety and reliability of the wires being tested.
DC Leakage Current Test
The Low Voltage Wire Tester can detect and measure DC leakage current within the range of 0.1μA-5mA, providing accurate and reliable results. This feature is essential for identifying potential faults and issues in low voltage circuits.
OS Test
This tester also includes an OS (open-short) test function, which can measure resistance levels within the range of 2kΩ-200kΩ. This feature is useful for detecting open or short circuits in low voltage wires and terminals.
Key Features
The Low Voltage Wire Tester boasts the following key features:
- Accurate and precise testing results
- Multiple optional configurations for versatile testing
- Advanced diode and zener diode testing capabilities
- AC withstand voltage and DC leakage current testing
- OS test function for detecting open or short circuits
Conclusion
The Low Voltage Wire Tester is a multifunctional and reliable testing instrument that is essential for any professional working with low voltage wires. With its advanced features and optional configurations, it offers efficient and accurate testing for a wide range of low voltage applications.
Features:
- Product Name: Low Voltage Wire Tester
- Points: 128/ 256/ 512/ 1024...20248PIN
- 4-wire NTC testing:
- Temperature Determination
- Resistance Determination
- Comparison Determination
- AC withstand voltage test: 30V-1000V/±3%
- LCR Test Frequency: 50Hz-10kHz
- IR Test Accuracy:
- 1MΩ-100MΩ:±2%
- 100MΩ-1GΩ:±5%
- Key Features:
- Low Voltage Cable Test Device
- Low Voltage Wire Analyzer Tool
- Electrical Wire Voltage Detector
Technical Parameters:
| Product Name |
Low Voltage Wire Tester |
| Product Type |
Wire Voltage Tester for Low Voltage Applications |
| Other Names |
Low Voltage Cable Test Device |
| Dimensions |
483*265*510mm |
| Weight |
25kg/17kg |
| Points |
128/ 256/ 512/ 1024...20248PIN |
| OS Test Accuracy |
±5% |
| AC Withstand Voltage Test |
30V-1000V/±3% |
| IR Test Accuracy |
1MΩ-100MΩ:±2%/ 100MΩ-1GΩ:±5% |
| Test Mode |
4-wire/2-wire(mixed Test) |
| Customized Functions |
Customized Functional Board |
| DC Resistance Test |
0.1Ω-1MΩ |
| DC Resistance Test Accuracy |
＜100K:±1%/＞100K:±5% |
Applications:
Low Voltage Wire Tester - SAIMR5000
Brand Name: SAIMR
Model Number: SAIMR5000
Place of Origin: CHINA
Certification: CE, ISO9001
Minimum Order Quantity: 1 SET
Price: To be negotiated
Packaging Details: Packing in wooden crates
Delivery Time: To be negotiated
Payment Terms: To be negotiated
Supply Ability: To be negotiated
Customized Functions: Customized Functional Board
Dimensions: 483*265*510mm
IR Test: 1MΩ-10GΩ(30V-1500V)
Weight: 25kg/17kg
Product Description:
The SAIMR5000 Low Voltage Wire Tester is a revolutionary tool for analyzing and testing low voltage wires. Designed and manufactured by SAIMR, a leading brand in the electrical industry, this wire voltage tester is a must-have for any professional or DIY enthusiast working with low voltage applications.
With its compact design and advanced features, the SAIMR5000 is the perfect tool for accurately measuring and testing low voltage circuits. Whether you are working on household wiring, automotive electronics, or industrial installations, this wire voltage meter is an essential tool for ensuring safety and efficiency.
Application:
The SAIMR5000 Low Voltage Wire Tester can be used in a variety of applications, including but not limited to:
- Household wiring
- Automotive electronics
- Industrial installations
- Low voltage lighting systems
- Telecommunications
- And more
Key Features:
- Customized Functional Board - The SAIMR5000 allows for customized functions to be added to the board, making it versatile and adaptable to various testing needs.
- Compact Design - With dimensions of 483*265*510mm, this wire voltage tester is lightweight and portable, making it easy to use in any environment.
- IR Test - The SAIMR5000 has a wide range of IR testing capabilities, from 1MΩ to 10GΩ, and can handle voltage levels from 30V to 1500V.
- Accurate and Reliable - This product has been certified by CE and ISO9001, ensuring its accuracy and reliability in testing low voltage wires.
Package and Delivery:
The SAIMR5000 Low Voltage Wire Tester is carefully packed in wooden crates to ensure its safety during transportation. The delivery time can be negotiated according to your specific needs and requirements.
Ordering Information:
To purchase the SAIMR5000 or for more information, please contact our sales team. We can negotiate the price and delivery time based on your order quantity and location. We also offer customized functions to meet your unique testing needs.
Conclusion:
The SAIMR5000 Low Voltage Wire Tester is an essential tool for any professional or DIY enthusiast working with low voltage circuits. With its advanced features, accuracy, and versatility, it is a must-have for ensuring safety and efficiency in various applications. Contact us today to order your SAIMR5000 and experience the difference in wire testing.
Customization:
Customized Service for Low Voltage Wire Tester - SAIMR5000
Brand Name: SAIMR
Model Number: SAIMR5000
Place of Origin: CHINA
Certification: CE,ISO9001
Minimum Order Quantity: 1 SET
Price: To be negotiated
Packaging Details: Packing in wooden crates
Delivery Time: To be negotiated
Payment Terms: To be negotiated
Supply Ability: To be negotiated
DC Resistance Test: 0.1Ω-1MΩ
AC leakage current test: 1μA-10mA
Dimensions: 483*265*510mm
4-wire NTC testing: Temperature Determination, Resistance Determination, Comparison Determination
IR Test Accuracy: 1MΩ-100MΩ:±2%/ 100MΩ-1GΩ:±5%
Key Features:
- Multifunction Tester for Low Voltage Wires
- Low Voltage Wire Current Tester
- Wire Voltage Meter for Low Voltage Circuits
FAQ:
What is the difference between a low-precision wire tester and a high-precision wire tester?
Measurement accuracy: Low-precision testers typically have a larger error range and are suitable for applications with lower measurement accuracy requirements; high-precision testers have higher measurement accuracy and are suitable for applications with higher measurement result requirements.
Measurement range: Low-precision testers usually have a narrower measurement range, while high-precision testers may have a wider measurement range.
Price: Generally speaking, high-precision testers are relatively more expensive, while low-precision testers are relatively less expensive.
Application scenarios: Low-precision testers are suitable for general wire testing needs, such as household appliance repair; high-precision testers are commonly used in industrial production, scientific research experiments, and other fields.
