SAIMR5000 INTRODUCTION

Product Description:

The Automatic Cable Harness Tester is a cutting-edge testing equipment designed for efficient and accurate testing of cable harness assemblies. This remote-controlled tester is equipped with advanced features to ensure reliable and precise testing results, making it an essential tool for any cable harness manufacturer.

• Automatic Wiring Assembly Tester: This tester is specifically designed for testing cable harness assemblies, making it a perfect fit for any cable harness manufacturing process.
• Remote-Controlled Cable Harness Tester: The tester can be operated remotely, providing convenience and flexibility for the user.
• DC Withstand Voltage Test: The tester is capable of performing DC Withstand Voltage tests with a range of 30-1500V, ensuring the safety and durability of the cable harness assemblies.
• LCR Test: The tester can perform LCR tests with a frequency range of 50Hz-10kHz, ensuring the accuracy and efficiency of the testing process.
• OS Test: The tester can perform an open/short test with a voltage of 5V and a resistance range of 2kΩ-200kΩ (optional 20kΩ-1000kΩ) with an accuracy of ±5%, ensuring the quality and reliability of the cable harness assemblies.
• RH: The tester has a relative humidity (RH) setting of 65%, providing optimal testing conditions for the cable harness assemblies.
• Electric Power Source: The tester is powered by electricity, making it a convenient and reliable testing equipment for any cable harness manufacturing process.

Features:

• Product Name: Automatic Cable Harness Tester
• DC Leakage Test: 0.1μA-5mA
• Four-wire DC Resistance Test: 10μΩ-100Ω
• AC Leakage Test: 1μA-10mA
• OS test(5V): 2kΩ-200kΩ(optional 20kΩ-1000kΩ)/±5%
• Points: 128/256/512/1024/...20480
• Remote-Controlled Cable Harness Tester
• Automated Wire Harness Tester

Technical Parameters:

Applications:

The Automatic Cable Harness Tester is a state-of-the-art testing equipment designed and manufactured by SAIMR, a leading brand in China. This product, with the model number SAIMR5000, is specifically designed to test the quality and performance of various types of cable harnesses. It is a highly advanced and efficient machine that is suitable for a wide range of industries and applications.

The Automatic Cable Harness Tester is an essential tool for any company involved in the production or quality control of cable harnesses. It is highly versatile and can be used in a variety of industries such as automotive, aerospace, electronics, and more. It is an ideal choice for any scenario where cable harnesses are used, including:

• Manufacturing plants
• Assembly lines
• Quality control labs
• Repair and maintenance facilities
• Research and development centers

The SAIMR Automatic Cable Harness Tester boasts a number of impressive features and attributes that make it an invaluable tool for any company. These include:

SAIMR is a well-known and trusted brand in the testing equipment industry. The company has a strong reputation for producing high-quality and reliable products.

The SAIMR5000 is the model number of this particular Automatic Cable Harness Tester, which sets it apart from other models in the market. It is the latest and most advanced version of the product offered by SAIMR.

This product is proudly made in China, a country known for its advanced technology and high-quality manufacturing processes.

The SAIMR Automatic Cable Harness Tester is certified by CE and ISO9001, ensuring that it meets international standards for quality, safety, and performance.

Customers can purchase a single set of this product, making it suitable for both small and large businesses.

The price of this product is negotiable, making it accessible to companies of all sizes and budgets.

The Automatic Cable Harness Tester is packed and shipped in sturdy wooden crates to ensure its safe delivery to the customer.

The delivery time for this product can be negotiated, allowing customers to plan their purchases and projects accordingly.

Customers can negotiate the payment terms for this product, providing flexibility and convenience for both parties.

SAIMR has a strong supply chain and can negotiate the supply ability of this product to meet the demands of its customers.

The Automatic Cable Harness Tester has the capability to test up to 20480 points, providing high precision and accuracy in testing.

This product has a wide range of DC leakage test capabilities, making it suitable for testing a variety of cable harnesses.

The Automatic Cable Harness Tester requires a standard 220V AC power supply, making it easy to use in any setting.

With a frequency range of 50Hz-10kHz, this product can perform LCR tests with high precision and efficiency.

Customers have the option to configure their Automatic Cable Harness Tester with additional tools and accessories, such as a port adapter board, test line, computer, temperature probe, and multi-channel temperature module for more comprehensive and specific testing.

The SAIMR Automatic Cable Harness Tester is a smart wiring harness testing machine that offers advanced automated testing capabilities. It is a highly efficient and reliable tool that is suitable for a wide range of industries and applications. With its impressive features and optional configurations, this product is a must-have for any company involved in the production, quality control, or maintenance of cable harnesses.

Customization:

Brand Name: SAIMR

Model Number: SAIMR5000

Place of Origin: CHINA

Certification: CE,ISO9001

Minimum Order Quantity: 1 SET

Price: To be negotiated

Packaging Details: Packing in wooden crates

Delivery Time: To be negotiated

Payment Terms: To be negotiated

Supply Ability: To be negotiated

DC Resistance Test: 0.1Ω-1MΩ

Diode/Zener Diode: 0-10V/0.1mA/1mA

Operating Temperature: 0-40°C

AC Withstand Voltage Test: 30-1000V

Product Name: SAIMR5000

SAIMR5000 is a Remote-Controlled Cable Harness Tester designed and manufactured by SAIMR in CHINA. It is a highly advanced and efficient Automatic Wiring Assembly Tester that is specifically designed to meet the needs of your business. With its state-of-the-art technology and precision engineering, SAIMR5000 is the perfect Robotic Wire Harness Verification Equipment for your company.

At SAIMR, we understand the importance of customization and we strive to provide the best solutions to meet your specific requirements. That's why we offer a range of customization options for SAIMR5000 to ensure that it perfectly fits your business needs.

Our customization service includes:

• Adjusting the testing parameters to meet your specific needs
• Integrating additional features and functionalities
• Customizing the software interface for easy operation
• Designing a unique packaging solution for your product
• Providing training and technical support for your team

With our customization service, you can be assured of a tailored solution that is efficient, reliable and cost-effective. Let us help you take your business to the next level with our highly customizable SAIMR5000 - Automatic Cable Harness Tester.

FAQ:

 1. What is a low-voltage wiring harness comprehensive test system?

A low-voltage wiring harness comprehensive test system is a device used to test the performance of low-voltage wiring harnesses, such as connectivity, conductivity, insulation, and voltage resistance.

2. What are the testing requirements of the low-voltage wiring harness comprehensive test system?

- Conductivity test: Detect whether the wires in the wiring harness are conducting, and whether the resistance of the conductivity meets the requirements.

- Insulation test: Detect the insulation performance of the wiring harness to ensure that there will be no short circuit or leakage problems during use.

- Voltage resistance test: Detect the voltage resistance performance of the wiring harness under high voltage to ensure that the wiring harness can work normally in a harsh environment.

- Connection test: Detect whether the connectors in the wiring harness are connected properly, and whether the insertion and extraction force of the connectors meets the requirements.

- Wiring harness length test: Detect whether the length of the wiring harness meets the requirements.

3. Why is low-voltage wiring harness comprehensive testing necessary?

Low-voltage wiring harnesses are widely used in automobiles, electronics, and electrical appliances, and their quality is directly related to the safety and reliability of the product. Through the testing of the low-voltage wiring harness comprehensive test system, the performance of various items of the wiring harness can be effectively detected to ensure that the quality of the wiring harness meets the requirements.

4. What are the advantages of the low-voltage wiring harness comprehensive test system?

- Improve testing efficiency: Multiple performance tests can be performed simultaneously, which greatly improves testing efficiency.

- Improve test accuracy: Adopt advanced testing technology and equipment to improve test accuracy and ensure the accuracy of test results.

- Reduce testing costs: It can reduce the time and cost of manual testing, while improving the reliability and stability of testing.
