OEM Low Voltage Continuity Tester AC Withstand Voltage Test Machine 30-1000V

OEM Low Voltage Continuity Tester AC Withstand Voltage Test Machine 30-1000V

OEM low voltage continuity tester

low voltage continuity tester 1000V

low voltage tester 30-1000V

Place of Origin:

CHINA

Brand Name:

SAIMR

Certification:

CE,ISO9001

Model Number:

SAIMR5000

Contact Us

Request A Quote
Product Details
AC Withstand Voltage Test:
30-1000V
LCR Test:
50Hz-10kHz
Points:
128/256/512/1024/...20480
DC Resistance Test:
0.1Ω-1MΩ
RH:
65%
Optional Configuration:
Port Adapter Board, Test Line, Computer, Temperature Probe, Multi-channel Temperature Module
Four-wire DC Resistance Test:
10μΩ-100Ω
Operating Temperature:
0-40°C
Payment & Shipping Terms
Minimum Order Quantity
1 SET
Price
To be negotiated
Packaging Details
Packing in wooden crates
Delivery Time
To be negotiated
Payment Terms
To be negotiated
Supply Ability
To be negotiated
Product Description

Advanced Automated Wire Harness Tester with Optional Configuration for Temperature Testing

Low Voltage Wire Harness Test System-SAIMR5000

Product Description:



The Automatic Cable Harness Tester is a high-quality and efficient tool designed for testing cable harnesses accurately and quickly. It is a must-have for any manufacturing or repair facility that deals with cable harnesses. This innovative product is perfect for testing all types of cable harnesses, including those used in automotive, aerospace, and industrial applications.

Product Overview

The Automatic Cable Harness Tester is a remote-controlled testing device that can be operated via a PC. It is a compact and lightweight product with a weight of 25/17kg, making it easy to transport and use in different locations. The display is also PC-based, providing a user-friendly interface for easy operation and data analysis.

Features
  • Remote-Controlled: The Automatic Cable Harness Tester can be controlled remotely through a PC, making it convenient for the operator to perform tests from a distance.
  • Automated Wire Harness Tester: With its automated testing process, this product eliminates the need for manual testing, saving time and effort.
  • DC Resistance Test: The tester has a wide range of resistance testing capabilities, from 0.1Ω to 1MΩ, ensuring accurate and reliable results.
  • Power Source: The Automatic Cable Harness Tester runs on electricity, eliminating the need for batteries or other power sources.
  • AC Leakage Test: This product also has the capability to perform an AC leakage test, with a range of 1μA to 10mA, ensuring the safety and quality of the cable harnesses.
Benefits
  • Efficient Testing: The Automatic Cable Harness Tester is designed to test cable harnesses quickly and accurately, saving time and effort for the operator.
  • Cost-Effective: With its automated testing process, this product eliminates the need for additional manpower, making it a cost-effective solution for any facility.
  • Reliable Results: The wide range of resistance and leakage testing capabilities of this product ensures reliable and accurate results, ensuring the quality of the cable harnesses.
  • User-Friendly: The PC-based display and remote-controlled operation make this product easy to use, even for operators with minimal technical knowledge.
  • Portable: The compact and lightweight design of the tester makes it easy to transport and use in different locations, providing convenience for on-site testing.
Applications

The Automatic Cable Harness Tester is suitable for a wide range of industries and applications, including:

  • Automotive
  • Aerospace
  • Industrial
  • Electronics
  • Telecommunications
  • Medical

It is an essential tool for any facility involved in manufacturing, repairing, or maintaining cable harnesses.

Conclusion

The Automatic Cable Harness Tester is a state-of-the-art product that offers efficient and accurate testing of cable harnesses. With its remote-controlled operation, automated testing process, and wide range of resistance and leakage testing capabilities, it is a valuable tool for any facility. Its lightweight and portable design, along with its user-friendly interface, make it a must-have for any industry dealing with cable harnesses. Invest in the Automatic Cable Harness Tester today and improve your testing process for better results and increased productivity.



Features:

  • Product Name: SAIMR5000
  • Display: PC
  • RH: 65%
  • Test Mode: 4-Wire or 2-Wire (Mixed Test)
  • Diode/Zener Diode: 0-10V/0.1mA/1mA
  • Automated Wire Harness Tester
  • Automatic Wiring Assembly Tester
  • Smart Wiring Harness Testing Machine


Technical Parameters:

Points Dimensions Operating Temperature DC Resistance Test DC Withstand Voltage Test LCR Test OS test(5V) Optional Configuration IR Test Diode/Zener Diode
128/256/512/1024/...20480 483*265*510/483*183*510 0-40°C 0.1Ω-1MΩ 30-1500V 50Hz-10kHz 2kΩ-200kΩ (optional 20kΩ-1000kΩ)/±5% Port Adapter Board, Test Line, Computer, Temperature Probe, Multi-channel Temperature Module 1MΩ-10GΩ (30V-1500V) 0-10V/0.1mA/1mA


Applications:

Introduction to Automatic Cable Harness Tester - SAIMR5000

Are you tired of manually testing cable harnesses and wires? Do you want a reliable and efficient solution for your testing needs? Look no further, SAIMR presents the SAIMR5000 - an advanced, automated cable harness tester designed to make your testing process easier and more accurate.

Brand Name: SAIMR

SAIMR is a renowned brand in the field of testing and measuring equipment. With years of experience and expertise, SAIMR has become a trusted name among industries.

Model Number: SAIMR5000

The SAIMR5000 is the latest addition to our line of cable harness testers. It is equipped with advanced technology and features to provide accurate and efficient testing results.

Place of Origin: CHINA

SAIMR5000 is proudly designed and manufactured in China, ensuring high-quality standards and cost-effectiveness.

Certification: CE,ISO9001

Our product has been certified by CE and ISO9001, meeting international quality and safety standards.

Minimum Order Quantity: 1 SET

We understand the varying needs of our customers, and hence, we offer a flexible minimum order quantity of 1 set for the SAIMR5000.

Price: To be negotiated

We believe in providing competitive prices for our products, and the price of the SAIMR5000 can be negotiated based on your specific requirements.

Packaging Details: Packing in wooden crates

To ensure safe transportation, the SAIMR5000 is packed in sturdy wooden crates, providing protection against any damage during transit.

Delivery Time: To be negotiated

We understand the importance of timely delivery, and hence, the delivery time for the SAIMR5000 can be negotiated based on your location and urgency.

Payment Terms: To be negotiated

We offer flexible payment terms to our customers, and the payment terms for the SAIMR5000 can be discussed and negotiated based on mutual agreement.

Supply Ability: To be negotiated

The SAIMR5000 is in high demand and is manufactured in large quantities to meet our customers' needs. We can discuss and negotiate the supply ability based on your requirements.

Power Supply: 220V AC

The SAIMR5000 requires a standard power supply of 220V AC, making it suitable for use in most industrial settings.

Four-wire DC Resistance Test: 10μΩ-100Ω

The SAIMR5000 is equipped with a four-wire DC resistance test function, which can accurately measure resistance in the range of 10μΩ-100Ω, ensuring high precision testing results.

OS test(5V): 2kΩ-200kΩ(optional 20kΩ-1000kΩ)/±5%

The SAIMR5000 also has an OS test function, which can measure resistance in the range of 2kΩ-200kΩ (optional 20kΩ-1000kΩ) with an accuracy of ±5%, providing reliable testing results.

Display: PC

The SAIMR5000 comes with a PC as a display, making it user-friendly and easy to operate. The PC also stores testing data and results for future analysis.

IR test: 1MΩ-10GΩ(30V-1500V)

With an IR test function, the SAIMR5000 can accurately measure insulation resistance in the range of 1MΩ-10GΩ with a voltage range of 30V-1500V, making it a versatile and efficient testing equipment.

Application and Scenarios

The SAIMR5000 is designed for use in a variety of industries, including automotive, aerospace, telecommunications, and more. Its compact and portable design makes it suitable for both in-house and on-field testing scenarios. It can be used to test various types of cable harnesses, including flat cables, ribbon cables, and round cables.

Whether you need to test a single cable harness or multiple harnesses simultaneously, the SAIMR5000 can handle it all with its remote-controlled testing function. It can be easily operated by a single person, saving time and effort.

The SAIMR5000 is also equipped with a smart wiring harness testing function, which can detect and diagnose any faults or defects in the harnesses, ensuring high-quality and reliable products for your customers.

Overall, the SAIMR5000 is a high precision cable testing equipment that offers accurate and efficient testing results, making it an essential tool for any industry that deals with cable harnesses and wires.



Customization:

Customized Service for Automatic Cable Harness Tester - SAIMR5000

Brand Name: SAIMR

Model Number: SAIMR5000

Place of Origin: CHINA

Certification: CE, ISO9001

Minimum Order Quantity: 1 SET

Price: To be negotiated

Packaging Details: Packing in wooden crates

Delivery Time: To be negotiated

Payment Terms: To be negotiated

Supply Ability: To be negotiated

AC Leakage Test: 1μA-10mA

DC Withstand Voltage Test: 30-1500V

Type: Cable/Wire Harness Tester

Test Mode: 4-Wire or 2-Wire (Mixed Test)

Display: PC

Introducing the SAIMR5000, a state-of-the-art Automatic Cable Harness Tester designed for efficient and reliable testing of cable and wire harnesses. With our smart wiring harness testing machine, you can ensure the quality and safety of your products with ease.

Our Robotic Wire Harness Verification Equipment is built with advanced technology and precision to provide accurate results. It is suitable for a variety of industries, including automotive, aerospace, and electronics.

At SAIMR, we understand the importance of customization to meet the unique needs of our clients. Our team of experts will work closely with you to provide tailored solutions for your specific testing requirements.

With our Robotic Wire Harness Verification Equipment, you can perform AC leakage tests ranging from 1μA to 10mA and DC withstand voltage tests from 30-1500V. The 4-wire or 2-wire (mixed test) mode allows for versatile testing options.

The SAIMR5000 is designed to be user-friendly and easy to operate, with a PC display for clear and detailed results. It is also CE and ISO9001 certified, ensuring top-notch quality and reliability.

Choose SAIMR as your partner for efficient and accurate cable and wire harness testing. Contact us now to discuss your testing needs and receive a customized quote.



FAQ:

.1. What are the advantages of the low-voltage wiring harness comprehensive test system in aerospace testing?

The low-voltage wiring harness comprehensive test system is suitable for aerospace testing because it has the following advantages:

- High-precision measurement: It can perform accurate electrical performance tests on low-voltage wiring harnesses, including resistance, capacitance, inductance, and other parameter measurements, ensuring the quality and reliability of the wiring harness.

- Multi-functional testing: The system can perform multiple tests, such as insulation resistance testing, conductivity testing, and voltage withstand testing, to comprehensively detect the performance of the wiring harness.

- Fault location: It can quickly locate faults in the wiring harness, helping maintenance personnel to troubleshoot and eliminate faults in a timely manner, improving maintenance efficiency.

- Data recording and analysis: The system can record test data and perform analysis, providing useful information for engineers, which helps to optimize the wiring harness design and improve product quality.

- Automation testing: It can realize automated testing, reducing the error caused by human operation and improving the accuracy and efficiency of testing.

- Adapt to harsh environments: It has good anti-interference ability and reliability, and can adapt to the harsh environmental conditions in the aerospace field.



2. How does the low-voltage wiring harness comprehensive test system ensure the safety of aerospace equipment?

The low-voltage wiring harness comprehensive test system ensures the safety of aerospace equipment in the following ways:

- Rigorous test standards: The system follows strict aerospace testing standards to ensure that the wiring harness meets relevant safety requirements.

- Comprehensive test items: It performs multiple tests, including insulation resistance, conductivity, and voltage withstand, to comprehensively detect the safety of the wiring harness.

- Fault early warning and alarm: Real-time monitoring of the test process, once abnormal conditions are detected, early warning or alarm signals are issued in a timely manner to avoid potential safety hazards.

- Data analysis and reporting: It provides detailed test data and reports, engineers can evaluate and improve the safety of the equipment based on data analysis results.

- Regular maintenance and calibration: The system requires regular maintenance and calibration to ensure the accuracy and reliability of the test results, thereby ensuring the safe operation of aerospace equipment. By using the low-voltage wiring harness comprehensive test system, aerospace testing can improve testing efficiency, reduce costs, and ensure the safety and reliability of equipment.
