Instruction Manual Wire Harness Testing Equipment Cable Harness Tester 30kg

Testing Wire Harnesses for and Functionality with Wire Harness Testing Equipment

Product Description:

Our Wire Harness Testing Equipment is a state-of-the-art product designed for comprehensive and accurate testing of wire harness assemblies. Featuring advanced technology and precise measurements, this equipment is a must-have for every manufacturer and quality control department.

Our Wire Harness Testing Equipment is equipped with an AC Leakage Current Test function, capable of detecting a range of 1µA-10mA with an accuracy of ±3%. This feature is essential for ensuring the safety and quality of wire harnesses, as even small amounts of leakage current can lead to malfunctions or safety hazards.

For those looking for even more comprehensive testing, our Wire Harness Testing Equipment offers an optional Air Tightness Test feature. This feature allows for the testing of air tightness in a range of -80Pa to 100KPa, with a resolution of 1Pa. This test is crucial for applications where air tightness is critical, such as in aerospace or medical equipment.

Our Wire Harness Testing Equipment requires a standard power supply of 220V AC, making it easy to integrate into any testing environment. The equipment is designed to be energy-efficient, reducing overall power consumption and operating costs.

The OS Test function of our Wire Harness Testing Equipment allows for the testing of open circuits in a range of 2kΩ-200kΩ with an accuracy of ±5%. This feature is essential for identifying any faulty connections or breaks in the wire harness assembly, ensuring the highest level of quality and reliability.

Our Wire Harness Testing Equipment also comes equipped with an AC withstand voltage test function, with a range of 30V-3000V and an accuracy of ±3%. This test is crucial for ensuring the insulation and safety of wire harness assemblies, as it can detect any defects or weaknesses that could lead to electrical hazards.

Our Wire Harness Testing Equipment is a highly versatile product that can be used for testing a wide range of connector cables. With its advanced technology and precise measurements, this equipment is capable of accurately testing various types of connectors and cables, making it an essential tool for any manufacturer or quality control department.

Our Wire Harness Testing Equipment is specifically designed for testing cable assemblies, making it the ideal choice for manufacturers in various industries such as automotive, aerospace, and electronics. With its comprehensive range of testing functions and advanced features, this equipment ensures the highest level of quality and reliability for all types of cable assemblies.

Overall, our Wire Harness Testing Equipment is an essential product for any manufacturer or quality control department looking to ensure the safety, reliability, and quality of their wire harness assemblies. With its advanced technology, precise measurements, and versatile testing capabilities, this equipment is a valuable investment that will save time, money, and effort in the long run.

Features:

• Product Name: SAIMR7000
• Standard feature: Switch Test
• Power Supply: 220V AC
• Standard configuration: Instruction Manual, Power Cord, Network Cable, And Pointing Pen.
• DC Leakage Current Test: 0.1µA-5mA/±3%
• Wiring Harness Quality Control Machine
• Electrical Wire Testing Device
• High precision testing for wire harnesses
• Accurate and reliable results
• Easy to use and operate
• Compact and portable design
• Wide range of testing capabilities
• Efficient and time-saving testing process
• Highly efficient in detecting faulty connections or wiring
• Ensures compliance with safety standards
• Provides detailed testing reports
• Durable and long-lasting construction

Technical Parameters:

Applications:

Are you looking for a reliable and efficient way to test your wire harnesses and cable assemblies? Look no further than the SAIMR7000 Wire Harness Testing Equipment. This cutting-edge product is designed to provide a comprehensive solution for testing the quality and performance of your cable assemblies, connectors, and electrical components. With its advanced features and user-friendly interface, the SAIMR7000 is the perfect choice for industries such as automotive, aerospace, and electronics.

The SAIMR7000 is a top-of-the-line cable assembly test equipment that is manufactured by SAIMR, a trusted brand in the industry. It is designed to meet the demanding requirements of modern cable assembly testing, providing accurate and reliable results every time. The product is manufactured in China and is certified with CE, ensuring its quality and safety standards.

The SAIMR7000 is proudly manufactured and marketed under the brand name SAIMR, known for its high-quality and innovative testing equipment.

This model number is a unique identifier for the SAIMR7000 Wire Harness Testing Equipment, making it easy to identify and order.

The SAIMR7000 is manufactured in China, utilizing the latest technology and high-quality materials.

Certified with CE, the SAIMR7000 meets the safety and quality standards required for use in various industries.

The minimum order quantity for the SAIMR7000 is 1 set, making it easy to purchase and use for smaller-scale testing needs.

The price of the SAIMR7000 can be negotiated, making it a flexible and cost-effective solution for your testing needs.

The SAIMR7000 is carefully packaged in wooden crates to ensure safe delivery and protection during transportation.

The delivery time for the SAIMR7000 can be negotiated, allowing for flexibility and timely delivery based on your specific needs.

The payment terms for the SAIMR7000 can be negotiated, providing you with the flexibility to choose a payment method that works best for you.

The supply ability for the SAIMR7000 can be negotiated, ensuring that you can easily meet your testing demands.

The SAIMR7000 is equipped with a switch test feature, allowing for efficient testing of switch connections and functionality.

The SAIMR7000 Wire Harness Testing Equipment is suitable for a wide range of applications and scenarios. Here are some of the key industries and scenarios where this product can be used:

The SAIMR7000 is an ideal solution for testing the quality and performance of cable assemblies used in industries such as automotive, aerospace, and electronics. It can accurately test for AC, DC, resistance, insulation, and dielectric strength, ensuring your cable assemblies meet the required standards.

The SAIMR7000 is also suitable for testing the quality and functionality of electrical connectors used in various industries. With its advanced features, it can accurately analyze and validate the performance of connectors, ensuring they meet the required standards.

The SAIMR7000 can be used as a validation equipment for electrical connectors, ensuring they meet the necessary safety and performance standards. It is an essential tool for industries such as automotive and aerospace, where the reliability of electrical connections is crucial.

The SAIMR7000 is a powerful testing equipment that can handle a wide range of testing needs. Its power varies depending on the position, making it suitable for different testing scenarios. Additionally, it can perform a DC withstand voltage test of up to 4000V with a ±3% accuracy, ensuring accurate and reliable results.

The SAIMR7000 Wire Harness Testing Equipment is a versatile and reliable solution for all your cable assembly testing needs. With its advanced features, user-friendly interface, and flexible options, it is the perfect choice for industries that require high-quality and accurate testing results. So why wait? Contact us today to learn more about the SAIMR7000 and how it can benefit your business.

Customization:

Our SAIMR7000 Wire Harness Testing Equipment is a top-of-the-line product that is customizable to fit your specific needs. With our advanced technology and high-quality materials, our equipment is designed to provide accurate and reliable testing of wire harnesses for functionality and quality.

Our optional feature of Air Tightness Test allows for a wide range of pressure testing to ensure the tightness and durability of your wire harnesses. With a resolution of 1Pa, our equipment is able to accurately detect any air leaks in your harnesses.

The SAIMR7000 also offers a range of points, from 16 to 20480PIN, to accommodate the size and complexity of your wire harnesses. This ensures that our equipment can handle any type of wire harness testing, no matter the scale.

In addition, our AC Leakage Current Test feature provides precise measurements of 1µA-10mA/±3%, allowing for thorough validation and quality control of your wire harnesses.

As a standard feature, our equipment also includes a Switch Test function that allows for quick and efficient testing of switches within your wire harnesses.

With our SAIMR7000 Wire Harness Testing Equipment, you can trust that your wire harnesses will be thoroughly tested and validated for optimal functionality and quality. Contact us today to discuss your customization options and receive a quote.

Packing and Shipping:

Our Wire Harness Testing Equipment is carefully packaged to ensure safe delivery to our customers. We use high quality materials and techniques to protect the equipment during transit.

The equipment is first wrapped in a layer of bubble wrap to prevent any damage from impact. It is then placed in a sturdy cardboard box, which is sealed with strong packaging tape.

For international shipments, the equipment is securely placed in a wooden crate to provide additional protection during long distance transportation.

Each package is labeled with the product name, model number, and any special handling instructions. This ensures that our customers receive the correct equipment and can handle it properly upon arrival.

We work with trusted and reliable shipping carriers to ensure timely and safe delivery of our products. We offer both standard and expedited shipping options to meet our customers' needs.

Thank you for choosing our Wire Harness Testing Equipment. We are committed to providing the best packaging and shipping services to ensure your satisfaction with our product.

FAQ:

FAQ on Medium and High Voltage Harness Integrated Test System in PDU:

Q: What is a medium and high voltage harness integrated test system?

A: It is a device used to test and verify the performance and reliability of medium and high voltage harnesses.

Q: Why is a medium and high voltage harness integrated test system needed in a PDU?

A: The PDU is responsible for distributing power to different loads, and the medium and high voltage harness integrated test system can ensure the normal connection of the harness in the PDU and reliable power transmission to ensure the normal operation of the entire system.

Q: How does a medium and high voltage harness integrated test system work in a PDU?

A: The system performs electrical performance tests on the harness in the PDU, including resistance, insulation resistance, and voltage withstand, to detect the connection quality and insulation performance of the harness.

Q: What faults can a medium and high voltage harness integrated test system detect?

A: It can detect problems such as circuit breaks, shorts, poor contacts, and insulation faults in the harness, helping to identify potential fault hazards in a timely manner.

Q: What is the impact of a medium and high voltage harness integrated test system on the performance of a PDU?

A: By using the system for regular testing and maintenance, the reliability and stability of the PDU can be improved, the probability of failures can be reduced, and the service life of the equipment can be prolonged.

Q: How to choose a medium and high voltage harness integrated test system suitable for a PDU?

A: When choosing a system, factors such as the voltage level of the PDU, the type of harness, and the testing requirements need to be considered, and a test system with corresponding functions and performance is selected.
