Product Description

1.DESCRITION

The SAIMR5000 can be customized into a transient breaking tester.Transient breaking tester is a special instrument used to monitor whether the wires and components connected by electrical connectors will suddenly experience instantaneous circuit breaking during dynamic load environmental tests such as vibration, impact, and collision. The transient breaking tester can detect the location and time of the transient breaking, and is used to determine the contact reliability of wires, connectors and other components during dynamic use.

2.USAGE

Connect the transient breaking tester to the computer, open the software on the computer, and set the parameters.
Connect the wiring harness to the transient breaking tester, press the test button, and start the test.
After the test, the software will automatically generate a test report, and the user can view the test results.

3.Specification

Low Voltage test	SAIMR5000
Test Mode	Four- wire or 2-wire (mixed test)
Number of Points	128/256/512/1024…20480
Test Project	Test Range	Test Accuracy
OS Test (Voltage 5V)	2 kΩ -200 kΩ (optional 20 KΩ -1000 KΩ)	±5%
Insulation Resistance Test	1MΩ-10 GΩ(30V-1500V)	1MΩ~100MΩ: ±2%
		100MΩ~ 1GΩ: ±5%
		1GΩ~ 10GΩ: ±10%
DC Resistance Test	0.1Ω-1MΩ	<100k: ±1%
DC Resistance Test	0.1Ω-1MΩ	>100k: ±5%
Internal Four-wire DC Resistance Test	0.1Ω-1MΩ	±0.5%+0.05Ω
Outer Four-wire DC Resistance Test	10μΩ~100Ω	±0.2%+5μΩ
Four-wire NTC Test (10k, 100k)	Temperature Judgment (accuracy 0.1°C)	Users can self-defined RT table for resistance and temperature judgment
	Resistance Judgment (accuracy 10k: 1% 100k: 5%)	The resistance value can be judged according to the real -time temperature of the environment
	Comparison Judgment (accuracy 0.1°C)	Maximum resistance difference between tested and standard parts (Range)
AC Hi-pot Test	30V-1000V	±3%
DC Hi-pot Test	30V-1500V	±3%
AC Leakage Current Test	1μA-10mA	±3%
DC Leakage Current Test	0.1μA-5mA	±3%
LCR Test	Frequency: 50Hz-10 kHz	100mΩ-20MΩ ±2%
	Test type: resistance / capacitor / inductance / impedance / conduction / conductance	10pF-100μF ±2%
	Test level: 0.1V-1.5V	10nH~100H ±2%
Diodes / Zener Diodes	0-10V	0.1 mA / 1 mA (test signal)
Dimensions (in mm)	483265510 (1024P)	483183510 (512P)
Maximum Weight (in kg)	25	17
Standard Configuration	User’s manual in U disk, power cord, network cable, port adapter board, test line, patrol pen.
Optional Configuration	Insulation standard resistance, conduction standard resistance, industrial computer, desktop computer, monitor, mouse, keyboard, speaker.

4. Low Voltage Transient Breaking Tester SAIMR5000 0
