Name: Handheld High Precision Battery Internal Resistance Tester Wide Range
Brand: Suzhou Saimr Electronics Technology Co., Ltd.
SKU: 3564
Price: Negotiable USD
Availability: InStock

Home > products > Battery Internal Resistance Tester >

Handheld High Precision Battery Internal Resistance Tester Wide Range

Wide Range Battery Internal Resistance Tester

High Precision Battery Internal Resistance Tester

Handheld Battery Internal Resistance Tester

Place of Origin:

China

Brand Name:

SAIMR

Certification:

Model Number:

3564

Request A Quote

Handheld High Precision Battery Internal Resistance Tester Wide Range

Product Details

Product Name:

Handheld Battery Internal Resistance Tester3564

Voltage Range:

10µV~1000V

Voltage Accuracy:

±0.02%

Resistance Range:

0.1µΩ~30Ω

Resistor Accuracy:

±0.5%

Range:

3m Ω, 30m Ω, 300m Ω, 3 Ω, 30 Ω:; 5 Full-range Automatic Or Manual Test Mode

Test Speed:

10 Times / S, 3 Times / S

Internal Data:

2400 Test Data (upgraded To 4800)

Calibration:

Short Circuit Clearance In Full Range

Payment & Shipping Terms

Minimum Order Quantity

1 SET

Price

To be negotiated

Packaging Details

Packing in wooden crates

Delivery Time

30 days

Payment Terms

To be negotiated, T/T

Supply Ability

To be negotiated

UPS Specialized Handheld Battery Internal Resistance Tester

Get Best Price

Bus Trigger Battery Internal Resistance Tester 100V AC-256V AC 50HZ/60HZ

Get Best Price

Ethernet Interface Battery Internal Resistance Tester With LCD Display

Get Best Price

Seven Gear Full Range Automatic Internal Battery Resistance Tester 100V AC-256V AC 50HZ/60HZ

Get Best Price

86-0512-62519606

sales2@saimr.com

Contact Now

Product Description

Handheld battery Internal Resistance Tester

1.Description:

Battery Internal Resistance Tester is a high precision, wide-range, and high-performance microprocessor-controlled device specifically designed for measuring the internal resistance of batteries. It covers an internal resistance range from 3mΩ to 3kΩ, with a minimum resolution of 0.1μΩ and a maximum display of 32000 numbers. The voltage range spans from 6V to 60V, featuring a minimum resolution of 10μV and a maximum display of 600000. The 3563 series instruments support the multi-channel scanning test function. By adding the company's multi-channel scanning tester, you can simultaneously scan and measure multiple batteries in different channels. This instrument is equipped with three communication interfaces, namely RS232/RS485/LAN, and comes with two sets of communication command protocols. When using Ethernet and RS232 communication, the instrument adopts the SCPI (Standard Command for Programmable Instrument). When using RS485 communication, the instrument utilizes the MODEBUS command protocol. Users can efficiently carry out remote control, data acquisition functions, and instrument networking.

The Battery Internal Resistance Tester can be utilized to test various types of batteries, including lithium batteries, nickel-metal hydride batteries, nickel-cadmium batteries, button batteries, cylindrical batteries, soft pack batteries, and so forth.

2. Parnter:

	SMR364	SMR364-A	SMR364-B	SMR364-D
voltage range	100µV~60V	10µV~100V	10µV~300V	10µV~1000V
voltage accuracy	±0.05%	±0.02%
Resistance range	1µΩ~3.1Ω	0.1µΩ~30Ω
Resistor accuracy	±1%	±0.5%
range	3mΩ,30mΩ,300mΩ,3Ω	3m Ω, 30m Ω, 300m Ω, 3 Ω, 30 Ω:; 5 full-range automatic or manual test mode
Test speed	1 time / second (average times optional)	10 times / s, 3 times / s
temperature	Range-10℃ -60℃ Precision: ± 1℃	Range-1℃ -60℃ accuracy: ± 1℃
internal data	Can record 2400 sets of test data	2400 test data (upgraded to 4800)
calibration	Short circuit clearance in full range
comparer	The FAIL / PASS comparison
trigger mode	Internal trigger, automatic trigger
joggle	USB interface, EXPORT end (port keeping execution function)
source	12V / 2500 mAh lithium battery 8 AA dry batteries; rated power: 4VA
size	208mm52.5mm120mm(LWH)
weight	0.81kg
appendix	SMR9363B, 9371, SMR9348, USBmini data cable, charger, 0370 strap

Handheld High Precision Battery Internal Resistance Tester Wide Range 0
