Name: UPS Specialized Handheld Battery Internal Resistance Tester
Brand: Suzhou Saimr Electronics Technology Co., Ltd.
SKU: 3564
Price: Negotiable USD
Availability: InStock

Home > products > Battery Internal Resistance Tester >

UPS Specialized Handheld Battery Internal Resistance Tester

UPS Battery Internal Resistance Tester

Specialized Battery Internal Resistance Tester

Handheld Battery Internal Resistance Tester

Place of Origin:

China

Brand Name:

SAIMR

Certification:

Model Number:

3564

Request A Quote

UPS Specialized Handheld Battery Internal Resistance Tester

Product Details

Product Name:

UPS Specialized Handheld Battery Internal Resistance Tester

Voltage Range:

10µV~1000V

Voltage Accuracy:

±0.02%

Resistance Range:

0.1µΩ~30Ω

Resistor Accuracy:

±0.5%

Range:

3m Ω, 30m Ω, 300m Ω, 3 Ω, 30 Ω:; 5 Full-range Automatic Or Manual Test Mode

Test Speed:

10 Times / S, 3 Times / S

Internal Data:

2400 Test Data (upgraded To 4800)

Calibration:

Short Circuit Clearance In Full Range

Payment & Shipping Terms

Minimum Order Quantity

1 SET

Price

To be negotiated

Packaging Details

Packing in wooden crates

Delivery Time

30 days

Payment Terms

To be negotiated, T/T

Supply Ability

To be negotiated

UPS Specialized Handheld Battery Internal Resistance Tester

Get Best Price

Bus Trigger Battery Internal Resistance Tester 100V AC-256V AC 50HZ/60HZ

Get Best Price

Ethernet Interface Battery Internal Resistance Tester With LCD Display

Get Best Price

Seven Gear Full Range Automatic Internal Battery Resistance Tester 100V AC-256V AC 50HZ/60HZ

Get Best Price

86-0512-62519606

sales2@saimr.com

Contact Now

Product Description

UPS Specialized Handheld Battery Internal Resistance Tester

1.Description:

UPS Specialized Handheld Battery Internal Resistance Tester is a high-precision, wide-range, and high-performance microprocessor-controlled apparatus specifically engineered for the measurement of the internal resistance of batteries. It encompasses an internal resistance range from 3mΩ to 3kΩ, with a minimum resolution of 0.1μΩ and a maximum display of 32,000 numbers. The voltage range extends from 6V to 60V, featuring a minimum resolution of 10μV and a maximum display of 600,000. The 3563 series instruments support the multi-channel scanning test functionality. By integrating the company's multi-channel scanning tester, it is feasible to concurrently scan and measure multiple batteries in distinct channels. This instrument is outfitted with three communication interfaces, namely RS232/RS485/LAN, and is accompanied by two sets of communication command protocols. When employing Ethernet and RS232 communication, the instrument adheres to the SCPI (Standard Command for Programmable Instrument). When utilizing RS485 communication, the instrument employs the MODEBUS command protocol. Users are capable of proficiently executing remote control, data acquisition functions, and instrument networking.

The UPS Specialized Handheld Battery Internal Resistance Tester can be employed to test diverse types of batteries, including lithium batteries, nickel-metal hydride batteries, nickel-cadmium batteries, button batteries, cylindrical batteries, soft pack batteries, and the like.

2. Parameter:

	SMR364	SMR364-A	SMR364-B	SMR364-D
voltage range	100µV~60V	10µV~100V	10µV~300V	10µV~1000V
voltage accuracy	±0.05%	±0.02%
Resistance range	1µΩ~3.1Ω	0.1µΩ~30Ω
Resistor accuracy	±1%	±0.5%
range	3mΩ,30mΩ,300mΩ,3Ω	3m Ω, 30m Ω, 300m Ω, 3 Ω, 30 Ω:; 5 full-range automatic or manual test mode
Test speed	1 time / second (average times optional)	10 times / s, 3 times / s
temperature	Range-10℃ -60℃ Precision: ± 1℃	Range-1℃ -60℃ accuracy: ± 1℃
internal data	Can record 2400 sets of test data	2400 test data (upgraded to 4800)
calibration	Short circuit clearance in full range
comparer	The FAIL / PASS comparison
trigger mode	Internal trigger, automatic trigger
joggle	USB interface, EXPORT end (port keeping execution function)
source	12V / 2500 mAh lithium battery 8 AA dry batteries; rated power: 4VA
size	208mm52.5mm120mm(LWH)
weight	0.81kg
appendix	SMR9363B, 9371, SMR9348, USBmini data cable, charger, 0370 strap

UPS Specialized Handheld Battery Internal Resistance Tester 0
