1 Channel DC Resistance Tester with Dimensions 325*215*96.5mm Accuracy 0.01%
Product Description:
The test range of SMR230 is 0.1 micro-ohm to 3.3 mega-ohm, with a basic accuracy of 0.02%. It meets the requirements of most resistance testing applications and has anti-interference design, which can complete accurate tests in various complex electromagnetic environments. It has fast and high-precision testing capabilities and can be used with software for NTC vibration testing.
Features:
Product Name: DC Resistance Tester
Test Project: DC Resistance/NTC
Dimensions: 325*215*96.5mm
Resolution: 0.1μΩ
Interface: LAN, RS232, IO
Number Of Channels: One/24PH/48PH
Technical Parameters:
Product Name
DC Resistance Tester
Dimensions
325*215*96.5mm
Comparator
10-bit Sorting
High/low/low Sorting
Measurement Range
0.1μΩ ~ 10MΩ
Weight
2kg
Storage Temperature
-10℃ ~60℃
Attachments
Power Cord, Test Clamp, Temperature Probe, Optional Probe Pen (multi-channel Models With Multi-channel Test Leads)
Resolution
0.1μΩ
Accuracy
0.01%
Test Mode
4-wire Or 2-wire (switchable)
Interface
LAN, RS232, IO
Applications:
DC Resistance Tester - SAIMR SMR230
Product Description
The DC Resistance Tester from SAIMR is a versatile and reliable tool for measuring electrical resistance in various products and materials. With its advanced features and user-friendly design, it is widely used in industries such as electronics, automotive, and aerospace for quality control and testing purposes.
Product Features
Brand Name: SAIMR
Model Number: SMR230
Place of Origin: CHINA
Minimum Order Quantity: 1 SET
Price: To be negotiated
Packaging Details: Packing in wooden crates
Delivery Time: 30 WORK DAYS
Payment Terms: To be negotiated
Supply Ability: To be negotiated
Storage Temperature: -10℃ ~60℃
Comparator: 10-bit Sorting, High/low/low Sorting
Weight: 2kg
Dimensions: 325*215*96.5mm
Test Mode: 4-wire Or 2-wire (switchable)
Price
To be negotiated
Packing and Shipping:
DC Resistance Tester Packaging and Shipping
The DC Resistance Tester is packaged with utmost care to ensure safe transportation and delivery. Each unit is securely packed in a sturdy cardboard box and sealed with tape to prevent any damage during transit. The packaging also includes foam padding and bubble wrap to provide extra protection against any external shocks or impacts. The box is labeled with the product name, model number, and any other relevant information for easy identification.
For shipping, we use reliable and trusted courier services to ensure timely and safe delivery of the product. The package is tracked throughout the shipping process to keep our customers informed about the status of their order. Additionally, we offer international shipping options for our global customers.
Our team takes great care in preparing and packaging the DC Resistance Tester to ensure it arrives in perfect condition to our customers. We strive to provide a hassle-free and satisfactory experience for our customers with our high-quality packaging and shipping services.
For any further inquiries or concerns regarding the packaging and shipping of the DC Resistance Tester, please feel free to contact our customer service team. We are always happy to assist you in any way we can.
FAQ:
.Q: What is the resistance test principle of SMR230?
A: The resistance test principle of SMR230 is based on Ohm's law, which states that the voltage across a resistor is directly proportional to the current passing through it. Specifically, SMR230 measures the voltage across and the current passing through the resistor, and calculates the resistance value.
Q: How does SMR230 perform resistance testing?
A: SMR230 uses a constant current source testing method, which applies a constant current to the resistor under test, measures the voltage across it, and then obtains the resistance value by dividing the voltage by the current. This testing method can avoid measurement errors caused by changes in the testing current, improving measurement accuracy.
Q: Does SMR230 have anti-interference design?
A: Yes, SMR230 incorporates anti-interference design, which enables accurate testing in various complex electromagnetic environments. These designs include shielding, filtering, grounding, and other measures that can effectively reduce the impact of external interference on test results.
Q: Can SMR230 perform data processing and analysis?
A: Yes, SMR230 can perform data processing and analysis through software to improve testing efficiency and accuracy.
