64 Point Evse Testing Equipment Evse Tester 1500*800*900 / 1200*570*630mm

Product Description:

The EV Charger Testing Equipment is a comprehensive and efficient device designed for testing and inspecting electric vehicle (EV) charging systems. This cutting-edge equipment is essential for ensuring the safety, reliability, and compliance of EV charging stations.

The EV Charger Testing Equipment is equipped with advanced features and capabilities that make it a valuable tool for EV power management testing. It is designed to accurately measure and evaluate various parameters of EV power supply, including storage, four-wire NTC (10K/100K), DC leakage current, and IR test. With customizable options, this equipment can be tailored to meet the specific needs and requirements of different EV charging systems.

Note: N/A - Not Applicable

• Efficient and reliable EV power supply tester
• Customizable four-wire NTC test for accurate measurement of temperature
• DC leakage current test with a range of 0.01mA to 6mA for precise evaluation of leakage current
• IR test with a range of 500kΩ to 10GΩ and an accuracy of ± 2%/± 5%/±10% for thorough insulation resistance testing
• Easy-to-use interface and customizable options for different EV charging systems
• Compact and portable design for convenient on-site testing
• Compliant with safety and quality standards for EV charging systems
• Cost-effective solution for EV charger inspection and maintenance

• EV Power Management Test Equipment
• EV Power Supply Tester
• EV Charger Inspection Device

Features:

• Product Name: EV Charger Testing Equipment
• Dimensions: 1500*800*900/ 1200*570*630mm
• DC resistance test Accuracy: ＜100mΩ:±1%(1μΩ)/ 100mΩ-1kΩ:±1%
• Weight: 50/60kg
• DC resistance test: Full Range
• AC leakage current test: 0.01mA-12mA/Step 0.01mA
• EV Charging Station Testing Device
• EV Charger Inspection Device
• EV Charger Inspection Device

Technical Parameters:

Applications:

SAIMR8000 is a high-precision and multifunctional EV charger testing equipment designed and produced by SAIMR, a leading manufacturer in China. This product is widely used in the testing and analyzing of EV power supply, charger performance, and electric vehicle charging system.

SAIMR8000 is equipped with advanced technology and high-quality components to ensure accurate and reliable test results. It is certified with CE and ISO9001, meeting international standards and ensuring the quality of the product. With a minimum order quantity of 1 set, customers can easily purchase and use it for their EV charger testing needs.

EV Charger Testing Equipment - SAIMR8000 is suitable for a variety of applications and scenarios, including:

• EV Power Supply Testing: SAIMR8000 can accurately measure the DC resistance of EV power supply, ensuring the safety and reliability of the power supply for electric vehicles.
• Charger Performance Analysis: With its high precision and multiple test points, SAIMR8000 can analyze the performance of EV chargers, helping manufacturers to improve the quality of their products.
• Electric Vehicle Charging System Testing: SAIMR8000 can test the DC withstand voltage of electric vehicle charging systems, ensuring the safety and stability of the system.

In conclusion, SAIMR8000 is a state-of-the-art EV charger testing equipment, designed to meet the demands of the fast-growing electric vehicle industry. With its high accuracy, multiple functions, and advanced technology, it is the perfect tool for EV power supply testing, charger performance analysis, and electric vehicle charging system testing. Contact us now to get a quote and experience the excellence of SAIMR7000!

Customization:

Introducing SAIMR's EV Charger Testing Equipment - a customizable service designed to meet the specific needs and requirements of your EV charging station. As a trusted brand in the industry, SAIMR offers the SAIMR8000 model which guarantees reliable and accurate performance testing for your EV power management system.

Our product is proudly made in CHINA and is certified with CE and ISO9001 standards, ensuring top-notch quality and safety. With a minimum order quantity of just 1 set, we provide flexible pricing options that can be negotiated to suit your budget.

The packaging of our EV Charger Testing Equipment is done in sturdy wooden crates to ensure safe and secure delivery. The exact delivery time and payment terms can also be negotiated according to your convenience.

One of the key features of our product is the customizable four-wire NTC test for 10K/100K sensors, allowing you to accurately measure temperature and control your charging process. Our Solenoid valve has a wide range of 50mA-2A with a voltage range of 0.2-40V for both continuous and pulsed operations.

Additionally, our AC withstand voltage test has a range of 10V-4000V (optional 5000V) with a step of 10mA. The test mode is a four-wire test for maximum accuracy and our equipment also has the added functionality of a switch test.

Choose SAIMR's EV Charger Testing Equipment for a fully customizable and efficient solution to test the performance of your EV charging station. Contact us now for more details and to discuss your specific requirements.

FAQ:

.FAQs for SAIMR8000:

1. What is SAIMR8000?

SAIMR8000 is a comprehensive test bench for high-voltage wiring harnesses, mainly used for testing new energy wiring harnesses.

2. What tests can SAIMR8000 perform?

SAIMR8000 can perform tests such as continuity, resistance/voltage drop, insulation resistance, high voltage withstand, NTC resistance, and air tightness.

3. What kind of test circuit board does SAIMR8000 have?

SAIMR8000 has two test circuit boards, each with 32 channels, for a total of 64 channels (128 points for four-wire measurement). The board has a high-voltage of 3.5KVAC and 5KVDC, and can be expanded later to increase the number of channels, such as 128P/256P/512P/1024P/2048P, etc.

4. What protection measures does SAIMR8000 have?

SAIMR8000 is equipped with overvoltage protection, overcurrent protection, leakage protection, and safety grating protection, which can maximize the protection of the operator's safety.

5. What kind of tests does SAIMR8000 support?

SAIMR8000 supports tests at any point-to-point.

6. What are the user-friendly designs of SAIMR8000?

SAIMR8000 has a user-friendly software interface that can help administrators quickly edit test procedures. It also has dual passwords for administrators and operators to ensure the controllability and security of the test program.

7. What data recording functions does SAIMR8000 have?

SAIMR8000 has the function of synchronous recording of test data, which can help customers keep abreast of product quality.

8. Does SAIMR8000 have a printer function?

SAIMR8000 has a printer function and can edit the print content arbitrarily. 9. Does SAIMR8000 support barcode scanning to automatically load test files and scan tests? SAIMR8000 supports barcode scanning to automatically load test files and scan tests. 10. Does SAIMR8000 support voice broadcast of test results? SAIMR8000 supports voice broadcast of test results.
