Wire Harness Testing Equipment

Product Description:

The Wire Harness Testing Equipment is a comprehensive and reliable wire bundle verification system designed for various electrical wire testing needs. It is an essential tool for ensuring the quality and safety of wire harnesses used in different industries such as automotive, aerospace, and electronics.

The Wire Harness Testing Equipment is available in a classic black and white color scheme, giving it a professional and sleek appearance. Additionally, our customers have the option to customize the color of their equipment to suit their brand or personal preference.

The Wire Harness Testing Equipment comes in different models with varying numbers of points to meet the specific needs of our customers. We offer models with 16, 32, 48, 64, and up to 20480 pins, providing a wide range of options for different wire harness testing requirements.

Our Wire Harness Testing Equipment is designed to operate with a power supply of 220V AC, making it compatible with most electrical systems. This ensures that the equipment can be used in various locations without the need for additional adapters or converters.

The Wire Harness Testing Equipment comes with a standard configuration that includes an instruction manual, power cord, network cable, and pointing pen. These accessories are essential for setting up and using the equipment effectively, ensuring a hassle-free testing experience for our customers.

The Wire Harness Testing Equipment is equipped with advanced testing functions, making it a versatile and comprehensive tool for wire harness testing. It can perform AC, DC, resistance, insulation, and dielectric strength testing, allowing for thorough and accurate assessment of the wire harness quality.

• Wire Bundle Verification System
• Electrical Wire Testing Device
• Wire Harness Tester
• Reliable and Accurate Testing Results
• Easy to Use and Maintain
• Durable and Long-lasting

With the Wire Harness Testing Equipment, you can trust that your wire harnesses will meet the highest quality standards, ensuring the safety and reliability of your products. Contact us today to learn more about our products and how they can benefit your business.

Features:

• Product Name: Wire Harness Testing Equipment
• Testing Modes: Manual, Semi-automatic, Fully Automatic
• Four-wire DC resistance test: 10µΩ-100Ω/±0.2%±5µΩ
• DC withstand voltage test: 30V-4000V/±3%
• Points: 16/32/48/64...20480PIN
• Dimensions: 535*482*355mm
• Connector Cable Test Analyzer
• Wiring Harness Quality Control Machine
• Wiring Harness Quality Control Machine

Technical Parameters:

Applications:

The SAIMR7000 Wire Harness Testing Equipment is a state-of-the-art solution for ensuring the quality and reliability of wire harnesses used in various industries. This product is designed and manufactured by SAIMR, a leading company in the electrical testing equipment industry. With its advanced features and precise testing capabilities, the SAIMR7000 is the ideal choice for any company looking to enhance their quality control process.

The SAIMR7000 is designed for the quality control of wiring harnesses in industries such as automotive, aerospace, and electronic manufacturing. It is used to test the electrical connectors, wire bundles, and other components of the harness to ensure they meet the required standards. This product is also suitable for testing custom-made wire harnesses used in specialized applications.

• Brand Name: SAIMR
• Model Number: SAIMR7000
• Place of Origin: CHINA
• Certification: CE
• Minimum Order Quantity: 1 SET
• Price: To be negotiated
• Packaging Details: Packing in wooden crates
• Delivery Time: To be negotiated
• Payment Terms: To be negotiated
• Supply Ability: To be negotiated
• Testing Modes: Manual, Semi-automatic, Fully Automatic
• Display: PC
• AC Leakage Current Test: 1µA-10mA/±3%
• DC Leakage Current Test: 0.1µA-5mA/±3%
• Testing Functions: AC, DC, Resistance, Insulation, Dielectric Strength

The SAIMR7000 is a highly versatile and reliable Wiring Harness Quality Control Machine that offers a comprehensive solution for testing the quality of wire harnesses. With its three testing modes - manual, semi-automatic, and fully automatic, it provides flexibility for different testing needs. The PC display allows for easy operation and monitoring of the testing process.

The AC and DC leakage current tests are crucial in identifying any potential faults or defects in the wiring harness. The SAIMR7000 can test for AC leakage current in the range of 1µA-10mA with an accuracy of ±3%, and for DC leakage current in the range of 0.1µA-5mA with an accuracy of ±3%. This ensures that the harness is safe and free from any leakage that could lead to electrical hazards.

In addition to leakage current tests, the SAIMR7000 also performs various other tests such as AC, DC, resistance, insulation, and dielectric strength. These tests help to verify the overall quality and performance of the wire harness, ensuring it meets the required standards and specifications.

The SAIMR7000 is packed in sturdy wooden crates to ensure safe transportation. The delivery time can be negotiated based on the customer's requirements and location. We offer flexible payment terms to suit our customer's needs.

The SAIMR7000 Wire Harness Testing Equipment is the perfect solution for companies looking to enhance their quality control process and ensure the reliability of their wire harnesses. With its advanced features and precise testing capabilities, it is a valuable asset in any industry where wire harnesses are used. Contact us today to learn more and negotiate the price and delivery terms.

Customization:

Brand Name: SAIMR

Model Number: SAIMR7000

Place of Origin: CHINA

Certification: CE

Minimum Order Quantity: 1 SET

Price: To be negotiated

Packaging Details: Packing in wooden crates

Delivery Time: To be negotiated

Payment Terms: To be negotiated

Supply Ability: To be negotiated

DC withstand voltage test: 30V-4000V/±3%

AC Leakage Current Test: 1µA-10mA/±3%

Four-wire DC resistance test: 10µΩ-100Ω/±0.2%±5µΩ

Standard configuration: Instruction Manual, Power Cord, Network Cable, And Pointing Pen.

Optional configuration: Port Adapter Board, Test Line, Computer, Temperature Probe, Multi-channel Temperature Module

Electrical Connector Validation Equipment

Electrical Wire Testing Device

Cable Assembly Test Equipment

Packing and Shipping:

Our Wire Harness Testing Equipment is carefully packaged to ensure safe and secure delivery to our customers. The packaging process follows strict guidelines to protect the equipment from damage during transit.

• All components of the Wire Harness Testing Equipment are securely wrapped and placed in a sturdy cardboard box.
• The box is sealed with high-quality packing tape to prevent any accidental opening during shipping.
• A layer of protective bubble wrap is added to the box to provide additional cushioning.
• The box is then placed in a larger shipping box and filled with packing peanuts to prevent shifting during transit.
• Finally, the shipping box is sealed with heavy-duty tape and labeled with the necessary shipping information.

We offer a variety of shipping options to meet our customers' needs:

• Standard Ground Shipping: Estimated delivery time of 3-5 business days within the continental United States.
• Expedited Shipping: Estimated delivery time of 1-2 business days within the continental United States.
• International Shipping: Estimated delivery time varies by location.

Customers can select their preferred shipping option at checkout.

For large orders or special shipping requests, please contact our customer service team for assistance.

Thank you for choosing our Wire Harness Testing Equipment. We strive to provide the best packaging and shipping experience for our valued customers.

FAQ:

Q: Which industries are suitable for medium and high voltage harness testers?

A: Medium and high voltage harness testers are widely applicable to the following industries:

1. Automotive industry: Used for testing and diagnosing automotive harnesses to ensure the connection quality and reliability of the harnesses.

2. Aerospace: Used for testing the harnesses of aircraft to ensure the normal operation of the harnesses under high pressure and harsh environments.

3. New energy: Used for testing the harnesses in the field of solar, wind and other new energies to ensure the efficiency of energy conversion and transmission.

4. Industrial automation: Used for testing the harnesses of industrial equipment to ensure the stable operation and safety of the equipment. 5. Rail transportation: Used for testing the harnesses of high-speed rail, subway and other rail transportation fields to ensure the safety and reliability of the vehicle.
